FR90 Single/Pairs

FD-90PP-5 Bonded

Features 90 min
SK Mineral Core

Door mineral core, 90 minute fire door with nominal thickness of 1-3/4”
Door composite mineral rails and stiles
Standard pairs with a 4’’ [101mm] wide meeting stile
Category B - Additional edge sealing required

Largest single swing 3’6” wide x 8’0” high [1067 x 2438 mm]
Largest standard pairs 7’0” wide x 8’0” high [2134 x 2438 mm]

Features 90 min
WSCP Mineral core
WSCP mineral core, 90 minute fire door with nominal thickness of 44mm (1-3/4”)
Tectonite composite mineral rails and stiles
Category B - Additional edge sealing required
Tested to CAN / ULC S104 (2015), UL 10 (c) (2016), UL 10 (b) (R2015), NFPA 252 (2017)

Largest single swing 3’6” wide x 9’0” high [1067 x 2743 mm]
Largest standard pairs 7’0” wide x 8’0” high [2134 x 2438 mm]

Frame options:

Category C – Standard/Proprietary, metal or mineral frame
Category H – Smoke & Draft Control Gasket

Hardware:

All hardware must be NFPA 80 compliant and listed.

NOTE: Door preparations in accordance with NFPA 80

 Models: Flush models - Essential Range

Finishes: Naturdor; Birch stain grade; White primed
